102mm Face Line Framing | Series 407

Series 407 FaceLINE™ shopfront framing system has been designed to complement AWS Series 406 FrontGLAZE™ and 702 & 704 SlideMASTER™ sliding doors.

102mm Face Line Framing | Series 407

Series 407 FaceLINE™ shopfront framing system has been designed to complement AWS Series 406 FrontGLAZE™ and 702 & 704 SlideMASTER™ sliding doors. Having glass close to the external face reduces the potential of dust build-up on transom ledges, interlocking split mullions to accommodate expansion and contraction, the 102 x 50mm framing system has a variety of transom and mullion alternatives, will accept glass from 6 to 10.38mm thickness, full perimeter frame allows this system to be fitted into sub-head, sub-sill and sub-jambs if required, four snap-on cover options, and being designed for one- or two-storey shopfronts, vertical should not exceed the stock length. This is not a curtain wall system.

Configurations

Available in a range of configurations to suit your needs

Colours

Make your own selection of colour finishes

Select from our popular colours or contact us to
see our complete colour range.

Anotec Natural Pearl

APO Grey

Custom Black

Dune

Monument

Paperbark

Pearl White

Primrose

Surfmist

Woodland Grey

Put the finishing touches on with a selection of hardware options

Maximum Panel Height*
Various
Maximum Panel Width*
Various
Maximum Glass Thickness
≤ 10.38mm
SHGC Range
0.33 – 0.73
Uw Range
4.3 – 6.1
Acoustics Testing Certified
AS2047 Testing Certified
WERS Rating

Frequently Asked Questions

What is the expected turnaround time for this product?

Our general lead time for products is approximately  5 – 6 weeks but this time can fluctuate depending on how busy our factory is. Please contact us to find out what our current lead time is.

Can I see this product in your showroom?

Our showrooms display the majority of the products we sell, allowing you to see, feel and experience them before you go ahead with your order. It also allows you to explore different styles and options in the decision making process.

Can you install this product?

We are a supply only company. This means you will need a builder or carpenter to install the products for you. If you need assistance finding an installer please talk to one of our sales reps who will be able to recommend an installer to you.

Do you make this product in custom sizes?

All our window and door products are custom made to the size that you need. We do not stock any windows and doors. The exception being Velux Skylights. They cannot be custom sized. We will order the size you request from their available options.

Is this product covered with a warranty?

Our window and door products have a 6 year warranty, this has some exclusions including any moving parts which have a 3 year warranty. Check out the full warranty details here

How do I get a quote to have this product in my project?

Fill out a quote request online and we will be in touch to finalise a quote with you. Or call us to talk to one of our experienced sales representatives today.

Shopfront framing system for your next commercial project
