Double Glazed Centre Glazed 102mm Framing | Series 424

Commercial Windows

Series 424 CentreGLAZE™ shopfront framing measures 102mm x 50mm and has been designed specifically to accept 24mm Insulating Glass Units (IGUs).

Double Glazed Centre Glazed 102mm Framing | Series 424

Series 424 CentreGLAZE™ shopfront framing measures 102mm x 50mm and has been designed specifically to accept 24mm Insulating Glass Units (IGUs). The 28mm deep glazing pocket is designed to accept thick heavy IGUs and allows glass to be installed easily with room to spare, this deep glazing pocket provides a 12mm bite as required by the IGU manufacturers and ensures compliance with glass warranties, reinforced tall glazing bead at sill tolerate high wind loads, true captive glazing wedge allows reglazing from inside – ideal in elevated applications, the captive wedge also offers increased security and the glazing wedges are recessed into the framing for a clean aesthetic. A wide range of sub-sills are available to cover most installations, including sub-sills with integrated nailing fin ideal for residential installations, sub-head and two piece sub-jambs, numerous door threshold options including weather resisting thresholds for external and internal swing doors, designed for use with Series 50, 51 and 52 commercial doors, compatible with Commercial and Architectural Series systems and accepts awning and Casement sashes.

Configurations

Available in a range of configurations to suit your needs

Colours

Make your own selection of colour finishes

Select from our popular colours or contact us to
see our complete colour range.

Anotec Natural Pearl

APO Grey

Custom Black

Dune

Monument

Paperbark

Pearl White

Primrose

Surfmist

Woodland Grey

Put the finishing touches on with a selection of hardware options

Maximum Panel Height*

Various

Maximum Panel Width*

Various

Maximum Glass Thickness

≤ 28mm

SHGC Range

0.17 – 0.63

Uw Range

2.6 – 3.6

Acoustics Testing Certified

AS2047 Testing Certified

BAL40 Testing Certified

Cyclone Certified

WERS Rating

Visit WERS

Frequently Asked Questions

What is the expected turnaround time for these products?

Our general lead time for products is approximately 5 – 6 weeks but this time can fluctuate depending on how busy our factory is. Please contact us to find out what our current lead time is.

Can I see this product in your showroom?

Our showrooms display the majority of the products we sell, allowing you to see, feel and experience them before you go ahead with your order. It also allows you to explore different styles and options in the decision making process.

Can you install this product?

We are a supply only company. This means you will need a builder or carpenter to install the products for you. If you need assistance finding an installer please talk to one of our sales reps who will be able to recommend an installer to you.

Do you make this product in custom sizes?

All our window and door products are custom made to the size that you need. We do not stock any windows and doors. The exception being Velux Skylights. They cannot be custom sized. We will order the size you request from their available options.

Is this product covered with a warranty?

Our window and door products have a 6 year warranty, this has some exclusions including any moving parts which have a 3 year warranty. Check out the full warranty details here

How do I get a quote to have this product in my project?

Fill out a quote request online and we will be in touch to finalise a quote with you. Or call us to talk to one of our experienced sales representatives today.
