Double Glazed Front Glazed 102mm Framing | Series 426

Double glazed FrontGLAZE™ framing system designed specifically to accept 24mm Insulating Glass Units (IGUs) with the required 12mm glass bite.

Double Glazed Front Glazed 102mm Framing | Series 426

Double glazed FrontGLAZE™ framing system designed specifically to accept 24mm Insulating Glass Units (IGUs) with the required 12mm glass bite. High water resistance can be achieved using the appropriate mullion and transom combinations. Has been successfully tested at 600Pa water resistance. The 102 x 60mm framing system has a variety of transom and mullion alternatives. This system will also accept many of the Series 400 CentreGLAZE™ frame accessories including doors, sub-frames and thresholds. The glazing pocket will accept co-extruded captive glazing wedges, Two mullion designs allow frames to be constructed with snap together mullion and expansion mullion with central weather leg for improved waterproofing, there’s an optional midrail which will also accept 24mm IGUs, transoms have a built-in drip groove to encourage water to leave the face of the framing and the sills and transoms are splayed at 25º to reduce the chance of dust and pollution build-up.

Configurations

Available in a range of configurations to suit your needs

Colours

Make your own selection of colour finishes

Select from our popular colours or contact us to
see our complete colour range.

Anotec Natural Pearl

APO Grey

Custom Black

Dune

Monument

Paperbark

Pearl White

Primrose

Surfmist

Woodland Grey

Put the finishing touches on with a selection of hardware options

Download Brochure
Maximum Panel Height*
Various
Maximum Panel Width*
Various
Maximum Glass Thickness
≤ 28mm
SHGC Range
0.18 – 0.66
Uw Range
2.7 – 3.6
Acoustics Testing Certified
AS2047 Testing Certified
BAL40 Testing Certified
WERS Rating

Frequently Asked Questions

What is the expected turnaround time for these products?

Our general lead time for products is approximately  5 – 6 weeks but this time can fluctuate depending on how busy our factory is. Please contact us to find out what our current lead time is.

Can I see this product in your showroom?

Our showrooms display the majority of the products we sell, allowing you to see, feel and experience them before you go ahead with your order. It also allows you to explore different styles and options in the decision making process.

Can you install this product?

We are a supply only company. This means you will need a builder or carpenter to install the products for you. If you need assistance finding an installer please talk to one of our sales reps who will be able to recommend an installer to you.

Do you make this product in custom sizes?

All our window and door products are custom made to the size that you need. We do not stock any windows and doors. The exception being Velux Skylights. They cannot be custom sized. We will order the size you request from their available options.

Is this product covered with a warranty?

Our window and door products have a 6 year warranty, this has some exclusions including any moving parts which have a 3 year warranty. Check out the full warranty details here

How do I get a quote to have this product in my project?

Fill out a quote request online and we will be in touch to finalise a quote with you. Or call us to talk to one of our experienced sales representatives today.

If this sounds like the right option for you make sure to add it to your quote
